STMicroelectronics L6470PD — IC MOTOR DRIVER BIPLR 36POWERSSO
Manufacturer part no. L6470PD
€17.20
In stock — 3755 unitslead time 693 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €17.20 |
| Shipping | €18.00 |
| VAT (20%) | €7.04 |
| Total delivered | €42.24 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €17.20 | |
| ≥ 10 | €13.71 | −20 % |
| ≥ 31 | €12.66 | −26 % |
| ≥ 124 | €11.76 | −32 % |
| ≥ 279 | €11.37 | −34 % |
| ≥ 527 | €11.13 | −35 % |
Datasheets & documents
2 offers for this product
Save up to €2.03 — cheapest in-stock offer at €18.61 incl. VAT.
| Seller | Availability | Price | |
|---|---|---|---|
| FarnellBest delivered cost | In stock· lead time 127 d | €15.51€18.61 incl. VAT | Visit ↗ |
| DigiKey | In stock· lead time 693 d | €17.20€20.64 incl. VAT | Visit ↗ |
Prices compared incl. VAT: some sellers list ex-VAT trade prices, others VAT-inclusive retail prices. The badge marks the best estimated delivered cost, shipping and duties included — not always the first row.
Specifications (automatically extracted)
Electrical
| Current | 3 A |
Other characteristics
| Applications | Usage général |
| Boitier | 36-PowerBSSOP (0,433po, 11,00mm de largeur) |
| Boitier fournisseur | PowerSO-36 Slug Up |
| Configuration de sortie | Demi-pont (4) |
| Fonction | Variateur - entièrement intégré, commande et étage de puissance |
| Interface | SPI |
| Resolution en pas | 1 ~ 1/128 |
| Technologies | DMOS |
| Temperature de fonctionnement | -40°C ~ 150°C (TJ) |
| Tension alimentation | 3,3V, 5V |
| Tension charge | 8V ~ 45V |
| Type de montage | Montage en surface |
| Type de moteur pas a pas | Bipolaire |
Compliance
| Moisture sensitivity (MSL) | 3 (168 heures) |
Description
DMOS Pilote de moteur Bipolaire SPI PowerSO-36 Slug Up
