DigiKeyRecom Power· Power supplies — board mount
Recom Power ROE-1205S — DC DC CONVERTER 5V 1W
Manufacturer part no. ROE-1205S
€3.60
In stock — 6077 unitslead time 182 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €3.60 |
| Shipping | €18.00 |
| VAT (20%) | €4.32 |
| Total delivered | €25.92 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €3.60 | |
| ≥ 5 | €3.47 | −4 % |
| ≥ 10 | €3.41 | −5 % |
| ≥ 25 | €3.34 | −7 % |
| ≥ 50 | €3.29 | −9 % |
| ≥ 100 | €3.23 | −10 % |
| ≥ 250 | €3.16 | −12 % |
| ≥ 500 | €3.11 | −14 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Current max. | 0.2 A |
| Power | 1 W |
| Voltage | 5 V |
Other characteristics
| Nombre de sorties | 1 |
| Rendement | 80 % |
| Tension entree max. | 13.2 V |
| Tension entree min. | 10.8 V |
| Tension isolement | 1 kV |
| Tension sortie 1 | 5 V |
| Applications | ITE (commercial) |
| Boitier | Module 4-SIP |
| Taille dimension | 0,45po L x 0,24po l x 0,39po H (11,5mm x 6,0mm x 10,0mm) |
| Temperature de fonctionnement | -40°C ~ 85°C |
| Type | Module isolé |
| Type de montage | Trou traversant |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Module isolé Convertisseurs CC/CC 1 Sortie 5V 200mA 10,8V - 13,2V Entrée
