BDE Technology BDE-BW2837 — Bluetooth/BLE, WiFi 2.4GHz, 5GHz
Manufacturer part no. BDE-BW2837
€21.86
In stock — 2000 unitslead time 7 d
- Conforme à RoHS
Estimated landed cost
| Item | €21.86 |
| Shipping | €18.00 |
| VAT (20%) | €7.97 |
| Total delivered | €47.83 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €21.86 | |
| ≥ 10 | €17.49 | −20 % |
| ≥ 100 | €15.74 | −28 % |
Datasheets & documents
Specifications (automatically extracted)
Other characteristics
| Debit de donnees | 54 Mbps |
| Puissance sortie | 16.5 dBm |
| Sensibilite | -95 dBm |
| Boitier | Module 100-SMD |
| Circuit integre composant utilise | WL1837 |
| Courant reception | 49mA ~ 85mA |
| Courant transmission | 243mA ~ 510mA |
| Frequence | 2,4GHz, 5GHz |
| Interfaces serie | SDIO, UART |
| Modulation | CCK, DSSS, GFSK, OFDM |
| Norme gamme rf | Bluetooth, WiFi |
| Programmable digikey | Non vérifié |
| Protocole | 802.11a/b/g/n, Bluetooth v5.1 BR / EDR / LE |
| Temperature de fonctionnement | -40°C ~ 85°C |
| Tension alimentation | 2,9V ~ 4,8V |
| Type d antenne | Antenne non incluse |
| Type de montage | Montage en surface |
Compliance
| Moisture sensitivity (MSL) | 3 (168 heures) |
Description
Bluetooth, WiFi 802.11a/b/g/n, Bluetooth v5.1 BR / EDR / LE Modules d'émetteurs-récepteurs RF 2,4GHz, 5GHz Antenne non incluse Montage en surface
Cheaper alternatives
Semantically close products available for less — check the specs match your need.
