RadioControlli RC-CC2652PA — Multiprotocol 2.4GHz wireless wi
Manufacturer part no. RC-CC2652PA
€21.86
In stock — 30 units
- min. order 2
- Conforme à RoHS
Estimated landed cost
| Item | €21.86 |
| Shipping | €18.00 |
| VAT (20%) | €7.97 |
| Total delivered | €47.83 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 2 | €21.86 | |
| ≥ 10 | €13.99 | −36 % |
| ≥ 30 | €11.37 | −48 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Frequency | 2 400 000 000 Hz |
Other characteristics
| Courant reception | 15 mA |
| Courant transmission | 180 mA |
| Puissance sortie | 18 dBm |
| Sensibilite | -103 dBm |
| Boitier | Module 40-SMD |
| Circuit integre composant utilise | CC2592, CC2652R |
| Interfaces serie | ADC, GPIO, I2C, I2S, SPI, UART |
| Norme gamme rf | 802.15.4, Bluetooth, bande ISM générale >1GHz |
| Protocole | 6LoWPAN, Bluetooth v5.0, Thread, Wireless M-Bus, Wi-SUN, Zigbee® |
| Temperature de fonctionnement | -30°C ~ 75°C |
| Tension alimentation | 2V ~ 3,6V |
| Type d antenne | Antenne non incluse, U.FL |
| Type de montage | Montage en surface |
Description
802.15.4, Bluetooth, bande ISM générale >1GHz 6LoWPAN, Bluetooth v5.0, Thread, Wireless M-Bus, Wi-SUN, Zigbee® Modules d'émetteurs-récepteurs RF 2,4GHz Antenne non incluse, U.FL Montage en surface
