DigiKeyXP Power· Power supplies — board mount
XP Power RBT20W24S05 — DC/DC CONVERTER 5V 10W
Manufacturer part no. RBT20W24S05
€4.13
In stock — 477 unitslead time 98 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €4.13 |
| Shipping | €18.00 |
| VAT (20%) | €4.43 |
| Total delivered | €26.56 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €4.13 | |
| ≥ 5 | €4.00 | −3 % |
| ≥ 10 | €3.88 | −6 % |
| ≥ 25 | €3.72 | −10 % |
| ≥ 100 | €3.46 | −16 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Current max. | 2 A |
| Power | 10 W |
| Voltage | 5 V |
Other characteristics
| Nombre de sorties | 1 |
| Rendement | 94 % |
| Tension entree max. | 36 V |
| Tension entree min. | 6.5 V |
| Tension sortie 1 | 5 V |
| Agence d homologation | CE, UKCA |
| Applications | ITE (commercial) |
| Boitier | Module 3-SIP |
| Numero standard | 62368-1 |
| Taille dimension | 0,45po L x 0,33po l x 0,69po H (11,5mm x 8,5mm x 17,5mm) |
| Temperature de fonctionnement | -40°C ~ 85°C (avec détarage) |
| Type | Module PoL non isolé |
| Type de montage | Trou traversant |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Module PoL non isolé Convertisseurs CC/CC 1 Sortie 5V 2A 6,5V - 36V Entrée
Cheaper alternatives
Semantically close products available for less — check the specs match your need.
